Description
Complete harness for passenger seat heating and airbag for Peugeot 3008 and 5008.
The complete wiring harness is designed as a direct replacement to restore passenger seat heating and SRS airbag connection. It connects the seat heating element and airbag squib to the vehicle electrical system using original-style connectors and secure routing to minimise chafing and interference. Frequently searched by technicians under part numbers 1602452-5 and 6545XV, this harness is a common fix for heating failures, airbag warnings, or intermittent seat-electrical faults on the right front passenger seat.
Technical Information
- Manufacturer: Stellantis (Peugeot)
- Model: Peugeot 3008 I, Peugeot 5008 I
- Product Codes: 1602452-5, 6545XV
- Additional Numbers: None
Installation Recommendations
- Disconnect Battery: Always disconnect the negative battery terminal and wait at least 10 minutes before starting work to reduce risk to SRS components.
- Seat Removal: For best access, remove the passenger seat following the vehicle manufacturer’s procedure.
- Connector Handling: Release retaining clips and unplug connectors carefully; avoid pulling on the wires themselves.
- Routing And Securing: Fit the harness following original routing lines and secure with clips away from seat rails and moving parts to prevent future abrasion.
- Diagnostics: After installation, verify SRS system status and seat heating operation with an appropriate diagnostic tool and clear any related fault codes.
- Skill Level: Suitable for experienced DIYers and professional mechanics. Because the harness involves airbag circuitry, professional installation is recommended if you are not fully confident.
Why This Part Most Often Fails
- Mechanical Fatigue: Repeated seat adjustment causes constant flexing, which eventually breaks wires at stress points.
- Chafing And Impact Damage: Incorrect routing, missing clips, or contact with sharp edges and seat rails leads to insulation wear and shorts.
- Moisture And Corrosion: Spilled liquids and humidity can corrode terminals and connector pins, causing intermittent faults or complete failure.
- Previous Improper Repairs: Non-OE splices or connectors reduce reliability and often lead to renewed faults or SRS warnings.
Search By Part Number: 1602452-5, 6545XV. Order this harness to quickly restore passenger seat heating and reliable airbag connection for your Peugeot 3008 / 5008.
