Seat belt buckle Citroën Peugeot 9816315480

€36.00

Stellantis CITROEN PEUGEOT
9816315480

1 in stock

SKU: 9983-H16_K4 Categories: , , ,

Description

Seat belt buckle for various CITROEN, PEUGEOT and other Stellantis models
Long – for the front passenger seat

Part description

This used seat belt buckle with product number 9816315480 in the long version is intended for the front passenger seat. It secures the seat belt tongue and releases it when exiting the vehicle. Correct latching and reliable retention of the belt are essential for passenger safety.

According to the available information, this part is listed for the Citroën Berlingo K9, PEUGEOT RIFTER and the other vehicles listed below. When selecting a part, compare the number 9816315480, length version and mounting with the original buckle in particular. The model name alone may not distinguish between all seat belt versions.

Technical information

  • Manufacturer: Stellantis – designation shown in the available information.
  • Model: Citroën Berlingo K9; FIAT DOBLO III; OPEL COMBO E K9; PEUGEOT RIFTER; Toyota ProAce City.
  • Part type: seat belt buckle.
  • Version: long.
  • Intended for: front passenger seat.
  • Condition: used part.
  • Other numbers: not specified.

Product codes

  • Product codes: 9816315480.

The product number is an important reference when looking for a replacement Citroën or Peugeot seat belt buckle. Before installation, also compare the design of the original and replacement parts.

Installation recommendations

The following applies generally to this type of part: the seat belt buckle is part of the safety system. The exact removal, fastening and any electrical connection procedures depend on the specific model and vehicle version. The available information does not state whether an electrical sensor or other system components are present. We recommend having the replacement carried out by a qualified mechanic in accordance with the manufacturer’s service procedure.

1) Before installation

  • Compare the product number, length, shape, mounting and any connectors with the old part.
  • Check the cover, mounting section and seat belt tongue entry. The part must not show cracks, deformation, significant corrosion or signs of forced tampering.
  • Check that the release button operates smoothly and that the matching tongue is securely retained. This check does not replace a professional safety assessment.
  • Do not install a part showing signs of accident-related stress or whose safe condition is in doubt. After an accident, follow the manufacturer’s instructions for the entire restraint system.

2) Required tools and materials

Typically, you will need suitable hand tools for the fasteners used, a torque wrench, tools for carefully releasing trim if necessary, a clean cloth and the vehicle’s service documentation. Whether new fasteners are required depends on the manufacturer’s instructions.

3) Step-by-step installation procedure

  1. Secure the vehicle against movement, switch off the ignition and ensure safe access to the work area.
  2. Refer to the service documentation for the replacement procedure and safety precautions for the specific version of the restraint system.
  3. If the work involves the electrical part of the restraint system, disconnect the battery and observe the waiting time specified by the manufacturer.
  4. If necessary, carefully remove any covers or other parts obstructing access. Note the orientation of the original buckle and the routing of any wiring.
  5. If the buckle is electrically connected, release the connector lock and disconnect it without pulling on the wires.
  6. Undo the fastener and remove the original buckle. Inspect the contact surfaces and anchor point; do not proceed with installation if they are damaged.
  7. Compare both parts again and position the replacement buckle in the correct orientation, without twisting or putting it under mechanical strain.
  8. Tighten the fastener according to the manufacturer’s service specifications. If the manufacturer requires the fasteners to be replaced, do not reuse the original ones.
  9. Reconnect any wiring and secure it so that it cannot be pinched or stretched when the seat moves. Reinstall any covers that were removed.
  10. Restore the power supply according to the manufacturer’s procedure if it was disconnected, and check operation before using the vehicle.

4) Post-installation checks and function test

With the vehicle stationary, buckle and unbuckle the seat belt several times. The tongue must audibly click into place, remain secured when pulled with moderate force and release when the button is pressed. Check that the buckle is firmly mounted and easily accessible with the seat in its normal adjustment range. If the vehicle has a seat belt warning system, check that it works as well. If there is a fault or a restraint system warning, do not use the passenger seat until the cause has been resolved. A test drive does not replace a safety function check.

5) Most common installation errors and how to prevent them

  • Confusing length or version: compare both the number and the physical characteristics of the parts before installation.
  • Incorrect orientation or tightening: follow the service procedure and do not guess instead of using the specified values.
  • Pinched wiring: route any wires away from moving parts and check them throughout the seat’s adjustment range.
  • Lubricating or dismantling the mechanism without the manufacturer’s instructions: do not spray universal lubricants into the buckle or interfere with its internal components.

Reasons why the part may become damaged

The following causes of damage may generally affect seat belt buckles; they do not describe the condition of the item offered for sale:

  • Wear of the mechanism from long-term buckling and unbuckling of the seat belt.
  • Dirt or foreign objects preventing the tongue from being fully inserted and secured.
  • Spills and moisture, which can cause corrosion or damage any electrical contacts.
  • Mechanical stress, impacts, pinching or forcibly inserting an unsuitable tongue.
  • Accident-related stress, which can also cause damage that is not immediately apparent.
  • Incorrect installation, improper fastening or damage to any wiring.

Additional information

Weight 1.2 kg

Unless otherwise specified in the description, all photos are for illustrative purposes only.

We reserve the right to replace the ordered reference with the manufacturer's replacement reference.

The parts come from crashed vehicles, are carefully inspected, and we provide a 12-month warranty on functionality for them.
