Description
Lock-Lock Cable 9138Q6 right rear door for Citroën C-Crosser Peugeot 4007
Right rear door control cable (Bowden/rods) for Citroën C -Crosser and Peugeot 4007. Original part PSA 9138Q6 with links to locks marked 9151CP and 9151CR. The ideal solution, if the rear right door (passenger party at the LHD) cannot be opened from the inside or from the outside, the handle has a heavy running or does not provide a lock. The original design ensures accurate storage in the door plate and trouble -free connection to the inner/outer handle and lock.
Why to reach the original ropes: exact length and endings, quiet and smooth operation, correct radius of guidance and long life. In the case of aftermarket replacements, we often encounter different shapes, inaccurate lengths and subsequent need for modifications. This part is from the car the same model line, so it fits without intervention.
Typical manifestations of defects and when to replace the cables:
- The handle goes hard or returns delayed
- doors do not open from the outside/inside (cracked or roded bowden)
- The lock does not delete despite the audible click of the actuator
- Damage of a tubing, corrosion or break of the cable in the endings
Basic installation instructions (informatively):
- Remove the door panel, carefully peel off the vapor -proof foil
- snap the ends of the cable from the outer and internal handles and from the lock
- guide the new cable in the original holders, pay attention to the correct break and storage of the tubing
- Click the endings, check free click and lock function before closing the door
Construction is a set of control cables between handles and lock. The cable transmits strength from the handle to the latch of the castle; Over time, the lubricant, suction of moisture and corrosion, or the wire rupture, which occurs with worse operation or complete malfunction. The replacement usually solves problems without having to change the entire lock if the lock itself is fine.
technical information
- Manufacturer: PSA – Citroën/Peugeot
- Model: Citroën C -Crosser; Peugeot 4007; Location: Right rear door
- product codes: 9138Q6; 9151CP; 9151Cr
- additional numbers: 9138.Q6; 9151.cp; 9151.CR; 9138 Q6; 9151 CP; 9151 Cr
Compatibility: Designed for Citroën C – Crosser and Peugeot 4007 with lock mechanism corresponding to codes above. Before ordering, we recommend comparing the numbers on your part and location (right rear doors).
