Description
Window and mirror control with frame for PEUGEOT 308 T9, the control itself without frame can be used on Citroen C4 SPACETOURER, C4 PICASSO 2014, C5 AIRCROSS, PEUGEOT 3008 and 5008
With the function of electric folding mirrors for the car
Part description
This window and mirror control is designed for PSA Citroën/Peugeot cars and comes with frame. It is a practical part for quick repair of malfunctioning window or mirror controls, including the function of electric folding mirrors. Thanks to the listed codes, you can easily find it even when searching by product number.
- Design: controller + frame
- Functions: window control, mirror control, electric mirror folding
Technical information
- Manufacturer: PSA Citroën Peugeot
- Model: Peugeot 308 T9 (as described); the controller itself without a frame can also be used on Citroen C4 SPACETOURER, C4 PICASSO 2014, C5 AIRCROSS, Peugeot 3008 and 5008
- Other numbers: 98031623ZD (frame)
Product codes
- Product codes: 98319761ZD, 98031623ZD
Installation recommendations
- Check that the part codes (98319761ZD) and frame (98031623ZD) match your original part before assembly.
- It is recommended to perform a visual inspection of the connectors and fixings (latches/packs) so that everything fits correctly in the door panel.
- After installation, check the functions: window control, mirror adjustment and electric folding mirrors.
Reasons why the part is damaged
- Mechanical wear of buttons and contacts during frequent use.
- Intrusion of moisture into the door (leakage, condensation) and subsequent corrosion of the contacts.
- Damage to the connector or wiring in the door (breaking wires in the grommet).
- Reckless disassembly/assembly – cracked frame handles or damaged latches.
