Description
Passenger airbag in the dashboard for Peugeot 207 vehicles. Single squib.
This passenger airbag module is a direct-fit safety component designed for the Peugeot 207. It is commonly searched by its part numbers and is intended for professionals and experienced DIY mechanics who perform SRS repairs. The module contains a single squib (pyrotechnic inflator) and is mounted in the dashboard on the passenger side. Replace the unit immediately after deployment or when the SRS system reports a fault involving the passenger airbag.
Technical Information
- Manufacturer: Stellantis / Peugeot
- Model: Peugeot 207
- Product Codes: 9685759080
- Additional Numbers: 8216WJ
- Number Of Squibs: 1 (Passenger Side)
Function
The passenger airbag is part of the Supplemental Restraint System (SRS). In the event of a qualifying collision the squib triggers the inflator, rapidly deploying the airbag to reduce impact forces on the occupant. The module works together with crash sensors and the airbag control unit to ensure timely deployment.
How It Is Replaced
Replacement requires careful handling because the module contains a pyrotechnic inflator and electrical connectors. Typical steps performed by a trained technician:
- Disconnect the negative battery terminal and wait the manufacturer‑recommended time to discharge the SRS capacitors (commonly 10–15 minutes or as specified by the vehicle manufacturer).
- Remove the necessary dashboard trim or glovebox to access the airbag module.
- Unscrew the retaining fasteners and carefully disconnect the electrical connector(s) with locking tabs.
- Install the new airbag module, connect the connector(s) securely and refit fasteners to the manufacturer torque specification.
- Reconnect the battery and clear SRS fault codes with a diagnostic tool; verify that the SRS warning lamp operates correctly.
Installation Recommendations
- Always disconnect the battery before starting work and follow Peugeot service procedures to avoid accidental deployment and damage.
- Use appropriate tools and a diagnostic scanner capable of reading and clearing SRS codes after installation.
- Do not attempt to open or modify the inflator or airbag module; handle and store the unit with the pad facing away from personnel.
- When refitting, follow the manufacturer’s torque values and connector locking procedures to ensure reliable electrical contact.
Most Common Failure Causes
- Prior Deployment: After a collision the inflator and bag must be replaced.
- Electrical Issues: Damaged wiring, corroded connectors or a failed squib can trigger SRS faults.
- Moisture And Corrosion: Water ingress behind the dash can degrade connectors and the inflator circuit.
- Physical Damage: Impact to the dash or improper handling during prior repairs can compromise the module.
- SRS Control Unit Faults: Problems in the airbag control unit or related sensors may present as passenger airbag errors even if the module itself is intact.
Additional Notes
This is a safety‑critical part; correct fitment and post‑installation diagnostics are essential. The part is often searched by part numbers 9685759080 and 8216WJ — include these codes when searching or ordering to improve compatibility match. For safe and reliable results, installation by a qualified technician or an experienced mechanic is recommended.
