Description
Complete combined instrument cluster for Citroën Berlingo II and Peugeot Partner II. Removed from a vehicle with 263,000 km.
Product Overview
This complete instrument cluster (tachometer cluster) is a direct-fit used unit suitable for Citroën Berlingo II and Peugeot Partner II models. It includes speedometer, tachometer, odometer, warning lamps and related gauges—ready for installation in vehicles that use the same cluster variant and connector layout. Ideal for professional workshops and experienced DIY mechanics who need a reliable replacement part with known part numbers.
Technical Information
- Manufacturer: Stellantis
- Model: Citroën Berlingo II, Peugeot Partner II
- Product Codes: 9662745180, 6105V8
- Additional Numbers: 6105V7, 6924K1
- Mileage: 263,000 km (unit removed from donor vehicle)
Features & Function
The instrument cluster displays vehicle speed, engine RPM, fuel level, temperature, odometer/trip readings and warning indicators (engine, ABS, airbag, etc.). It receives and transmits data over the vehicle network and processes inputs from sensors and control modules to present clear, real-time information to the driver.
Fitment / Compatible Vehicles
Designed for Citroën Berlingo II and Peugeot Partner II variants that use the listed cluster part numbers. Ensure the part numbers match the original unit in the vehicle. This cluster is intended for the second-generation Berlingo/Partner line that share the same dashboard electronics architecture.
Replacement Procedure
- Park vehicle on a level surface, set the parking brake and remove ignition key.
- Disconnect the negative battery terminal and wait at least 2 minutes to allow vehicle electronics to power down.
- Remove dashboard trim panels surrounding the instrument cluster. Keep screws and clips organized.
- Unscrew retaining bolts on the cluster and gently pull the unit forward to access electrical connectors.
- Carefully release connectors—do not pull on wiring—then remove the cluster.
- Install replacement cluster by reversing steps. Reconnect battery last and check all instrument functions and warning lights after power-up.
Installation Recommendations
Always disconnect the battery before beginning work and follow manufacturer guidelines to avoid damage to sensitive electronics. Handle the cluster by its housing and avoid touching circuit board areas or connector pins. After installation, verify communication with the vehicle network and confirm that all gauges and warning lamps operate correctly. If any indicators remain illuminated or functions do not respond, professional diagnostic equipment may be required to adapt or code the unit to the vehicle.
Why This Part Most Often Fails
Instrument clusters typically develop faults due to a few common causes: aged stepper motors or gauge mechanisms, cracked solder joints caused by thermal cycling, moisture ingress affecting printed circuit boards, and voltage spikes or electrical faults in the vehicle. Backlight failures and intermittent displays are frequent in high-mileage units. Regular electrical checks and ensuring stable vehicle voltage help prolong cluster life.
Suitable For
Recommended for garages and experienced DIYers needing a direct replacement cluster for Citroën Berlingo II and Peugeot Partner II where the part numbers match. Supplied as a used complete unit with the stated mileage value from the donor vehicle.
Final Notes
Check that the part numbers printed above correspond to the original unit in your vehicle before installation. If coding or adaptation is required after installation, seek assistance from a technician with PSA-compatible diagnostic tools to ensure full functionality.
