Description
Driver’s Seat Airbag For Citroën Xsara Picasso. Color HZM – BISE.
High-quality replacement driver’s seat airbag designed for Citroën Xsara Picasso owners and professional workshops. This unit is commonly searched by part numbers (96472197ZM, 8216S6) and fits original equipment specifications for a direct and reliable replacement. Ideal for mechanics and experienced DIYers who want a precise fitment and dependable operation after repair or post-collision replacement.
Function
The Seat Airbag Protects The Driver’s Torso And Pelvic Area In Side Impacts. Integrated Into The Seat Structure, It Works Together With Front And Curtain Airbags To Reduce Injury Severity During A Crash. The Module Contains Pyrotechnic Inflators And Occupant Detection Elements Where Applicable.
Compatibility And Models
Intended For Citroën Xsara Picasso Models (Produced 1999–2010). Frequently Identified By Part Numbers 96472197ZM And 8216S6. Always Check The Part Number To Ensure Correct Match; Many Customers Search Directly By These Codes.
Replacement Procedure
- Disconnect The Negative Battery Terminal And Wait Minimum 10 Minutes To Allow SRS Capacitors To Discharge.
- Remove The Seat From The Vehicle If Required For Access (Unbolt Seat Fixings And Disconnect Electrical Connectors).
- Carefully Remove Seat Trim Or Covers To Access The Airbag Module; Observe Airbag Handling Rules (Keep Inflator Face Up, Do Not Use Impact Tools On The Module).
- Disconnect Electrical Connectors And Unbolt The Airbag Module From The Seat Frame.
- Fit The Replacement Unit In Reverse Order. Ensure Connectors Are Fully Seated And Bolts Are Tightened To Manufacturer Torque Values.
- After Reconnection Of The Battery, Use An SRS-Capable Diagnostic Tool To Clear Fault Codes And Verify Proper System Status; Confirm That The Airbag Warning Light Behaves Normally.
Mounting Recommendations
- Work Should Be Carried Out By Trained Technicians Or Experienced DIYers Familiar With SRS Systems.
- Always Disconnect The Battery Before Any Work And Observe A Waiting Period (Minimum 10 Minutes) To Prevent Accidental Deployment.
- Follow Seat Manufacturer Instructions For Trim Removal To Avoid Damaging Clips And Upholstery.
- Use Correct Torque Settings For Seat And Airbag Fasteners. Replace Any Damaged Fixings.
- Verify Electrical Connections And Secure Any Loose Wiring. After Installation, Perform A Full SRS System Scan With A Diagnostic Tool Compatible With PSA Vehicles.
- Handle The Airbag Module Gently—Do Not Strike, Heat, Or Expose To Static Sources.
Most Common Failure Reasons
- Deployment After A Collision — Airbag Must Be Replaced If Deployed.
- Electrical Faults — Corroded Or Damaged Connectors, Broken Wires In Seat Harness, Or Faulty Clockspring Can Cause SRS Errors.
- Water Ingress Or Seat Damage — Moisture From Spills Or Flooding Can Corrode Contacts And Inflator Components.
- Mechanical Damage — Wear, Rusted Mountings Or Improper Previous Repairs Can Compromise The Module.
Technical Information
- Manufacturer: Stellantis (Citroën/Peugeot)
- Model: Citroën Xsara Picasso
- Product Codes: 96472197ZM, 8216S6, NFP
- Other Numbers: Color Code HZM – BISE
Important Notes
This Airbag Is A Safety-Critical Component. Improper Handling Or Installation Can Result In System Malfunction Or Personal Injury. After Installation, Always Verify SRS System Status With A Diagnostic Scanner And Ensure The Airbag Warning Light Returns To Normal.
